Shine Concept Private Limited is a manufacturer of LED lights in Thane, Mumbai working on the Atma Nirbhar Bharat Mission. The LED panel lights are designed to install in Residential, Office, Lobby areas, Hotels, Restaurants, Shops, and Showrooms. Shine designed these LED panels in a manner so that it occurs only 12mm high and fit as slim as they can be to fix any ceilings. Its clean and modern look helps the LED to spread smooth, uniform, and edge-to-edge light. Shine Concept designed these LED panels using PDC (High-Pressure Die Casting ) technology that gives a one-piece and uniform frame to each light.

Key Feature-

- Perfectly adaptable for the ceilings.

- Slimmest, Durable, long-lasting, and easy to install LED Panel lights.

- Integrated with Smart IC and isolated drivers that provide constant lights during facility.

- LED Panel Light panels integrated with the lens are available at the range of 4W, 6W, 9W, 12W, 15W, 18W, 22W, 26W, 36W, 48W, and 54W.

- It is available with a 2 years warranty and enough capable to burn more than 40,000 hours.

Technical Specification-

Supply Currents : 300-350Ma

Surge : 2KV

Mounting type : Recess

Input : 90-256VAC

Frequency : 50Hz

Working Temp :  0 °C to + 55 °C

Power Factor : > 0.96

Driver Efficiency : > 85%,  Constant Current (External)

Ingress Protection : IP 20

Working Life : 50,000 Hrs.

CRI : > 70

Physical Details-

Material : Aluminum Die cast

Dimensions : 150 x 150 x 12 MM

Cut out : 130 MM

Suitable Fixing : Recess Mount

Lumen Efficiency : 110 Lumen/Watt

Led Make : Edison

Color Temperature : 6500k – Cool White / 4000k – Natural White / 3000k – Warm White
