Shine Concept Private Limited is a manufacturer of LED lights in Thane, Mumbai working on the Atma Nirbhar Bharat Mission. It provides multiple light-weighted LED panels and light bulb strips for the House, Industry, Office, Commercial, Outdoor locations.

For Workplace, their High Bay Luminaires are ideal. It is suitable for supermarkets, large workshops, Steel mills, Warehouses, airports, Highway toll stations, Gas stations, Exhibition halls, Gymnasiums, Bus waiting rooms, Railway station waiting rooms, and other places requiring high space lighting.

Physical Details

Housing Material: Aluminium Die cast - High-purity aluminum radiator with high thermal conductivity

Reflector Material/ shape : Aluminium/Dome

Dimensions with reflector (dome) : φ290mm * H198mm

Net Weight: 1.4 kg

Gross weight: 1.6kg

Size of Color Box : 215mm*215mm*125mm

Suitable Fixing: Hoisting

Connection: Flying leads/wires

Cable: Cable 0.3 m without plug -0.75sq.mm, three-core cable, the brown wire is" L" wire, the blue wire is "N" wire, and the yellow-green wire is the "E".

Key Feature-

• High Bay LED lighting is designed with high-efficiency chip on board (cob) LEDs or SMD led’s and high purity anodized 120˚ aluminum reflector for superior performance.
• LED lights emit a wide and uniform light distribution throughout the facility.
• High Bay LED Panels are available at the range of 30W, 50W, 100W, 150W in Cool White, Pure White, Warm White colors.
• Dimensions : Diameter - 290 mm, Height - 160 mm with 90-280V input voltage.
• It is available with a 2 years warranty that makes it capable of burning 50,000 hours.
• ISI, CE, Rohs, UL Certified.
